CNC Milling and Deburring Machine

CNC Milling and Deburring Machine

We are prime Manufacturer, Exporter & Supplier of CNC Milling and Deburring Machine based in Maharashtra, India. The company has a team of skilled and well-qualified professionals who are aware about the latest techniques for manufacturing the product as per industry standards. We also provide Special Purpose Milling and Deburring Machines in tailor-made specifications, defined by the buyers, at reasonable rates.



Specifications

Machine

Milling & Deburring Spm – Model 976

Component

Twist Beam Welded Structure Assy.

Operation

Miling & Deburring of at both ends Camber plate

Cycle time(Output/hr)

120 Sec.(30/hr.)

Machine Description

Job is loaded in the fixture manually. Hydraulically clamped. An ISO50 milling spindle unit mounted on X and Z servo axis slide performs the facing operation in two pass on camber plate from both sides.



Y axis slide and one more spindle unit is provided to carry out deburring operation to the profile of camber plate using Y and X axis interpolation.
